DM-08 Newly designed Studio Mixer professional sound system mp3 music mixer dj

Main fuction:
One Group AUX output and One Group return.
High Precision 100mm long life fader.
With 16 DSP Digital effects
Dual 7 band EQ
It is independent listen each channel Recording
and headphone listen output .
High quality With MP3 player.
+48V Phantom power.
Technical Specification:
Channel MIC/LINE:8
Main BUS: 1 Stereo,
Channel EQ: 3 Band
Total Harmonic Distortion:≤0.05%
Frequency Response:18Hz~18KHz
S/N Ratio:≥80dB
Max Outputs:4V Max
input Sensitivity:Mic-60dB
Line-50dB
Input EQ:HI±15dB/12KHz
MID±15dB/2.5KHz
LOW±15dB/80Hz
Output Power: 4Ω 2/350W
Availability:
Quantity:
DM-08 Newly designed Studio Mixer professional sound system mp3 music mixer dj
DM-08 Newly designed Studio Mixer professional sound system mp3 music mixer dj
  • DM-08

  • AKB

Main fuction:

One Group AUX output and One Group return.

High Precision 100mm long life fader.

With 16 DSP Digital effects

Dual 7 band EQ

It is independent listen each channel Recording

and headphone listen output .

High quality With MP3 player.

+48V Phantom power.

Technical Specification:

Channel MIC/LINE:8

Main BUS: 1 Stereo,

Channel EQ: 3 Band

Total Harmonic Distortion:≤0.05%

Frequency Response:18Hz~18KHz

S/N Ratio:≥80dB

Max Outputs:4V Max

input Sensitivity:Mic-60dB

Line-50dB

Input EQ:HI±15dB/12KHz

MID±15dB/2.5KHz

LOW±15dB/80Hz

Output Power: 4Ω 2/350W
